Product Description:
Full Metal medium-sized electric retractable landing gear using 6061T6 aluminum CNC machining process for T810 / T960 / 810sport / 960sport and other multi-axis DIY use unmanned aerial vehicles (need to add drilling two M3 mounting holes, optional Long metal silicone damping seat 4). This is the similar products in the highest degree of product integration, the overall design of the structure is simple, quick and easy installation, small footprint. Exclusive ordered large torque motors reliable and durable performance.
The state intellectual property has been awarded the TAROT model., Ltd two patents. Any units orindividual without the license holder manufacture, copy, use and sale the product will be patent lawsuit.
patent number patent number: 201430262458.5
patent number patent number: 2014204282854
Related Item:
Electric retractable tripod controller TL8X002
Small electric retractable landing TL65B43
Small electric retractable landing gear group TL65B44
Medium-sized electric retractable landing TL8X003
X series electric retractable landing gear group TL8X001
Department of electric retractable landing gear group TL96030
Large electric retractable landing TL4N001
Large electric retractable landing gear group TL4N002
Product Specifications:
Pipe Clamp on Φ25MM metal (39 × 12.3 × 10MM) pitch Φ23MM
Φ25MM metal hose clamp under the seat (39 × 16.3 × 10MM) pitch M28MM
M3 × 20MM Cup hex head screws × 2
The M3 × 12MM Cup Head Cap Screws × 2
M3 × 8MM big step screw cap × 2
Full Metal medium-sized electric retractable landing control group × 1 (115 × 34 × 36.5MM) 77G
Φ4 × 6MM rivet × 2
Φ25MM 3K pure carbon tube × 1 (Φ25 × 23 × 349MM)
Φ25↔Φ16 plastic adapter seat TL96017 × 1 (Φ25 × 45MM)
The M2.5 × 25 × 1 cup head Allen screws
The M2.5 × 30 × 1 cup head Allen screws
M2.5 slip nut × 2
Φ16MM 3K pure carbon tube × 1 (Φ16 × 14 × 445MM)
Multi-axis shock tripod set TL96022 × 2 (Φ16 × Φ25.8 × 31MM)
